eSSL-Access-8004

Multidoor Access Control - 4 Door

Category:Door Controller

Features:
Card Capacity : 20,000,
Event buffer : 1,00,000,
Communication : TCP/IP 10M/100M adaptive,
Function Description : Control 4 doors, enter via cards swiping and exit via buttons ,
PCB board size : 21.9 * 12.2 * 3.4cm.

PDF Catalogue

Specifications

Technical Specifications

  • Card Capacity : 20,000
  • Event buffer : 1,00,000
  • Communication : TCP/IP 10M/100M adaptive
  • Function Description : Control 4 doors, enter via cards swiping and exit via buttons
  • PCB board size : 21.9 * 12.2 * 3.4cm
  • Controller case size : 273*228*65mm
  • Power supply : 12V DC 4-7A
  • Power consumption of circuit board : < 200mA
  • Reader input format : Wiegand 26/34
  • Card Reader supported : 4
  • Door control output : 4
  • Delay time for unlocking : 1-600 seconds(adjustable)
  • Operation Temperature : -40 °C - 70°C
  • Operation Humidity : 10-90 % RH, No Condensation
  • 256 time Zones, 256 access levels
  • Anti-passback function
  • Interlock function
  • Multi-Card Opening function, Remote door opening
  • Real-Time monitoring via software Power interruption protection measure : High Speed Memory, Records never lose
  • Max Distance between Controllers : TCP/IP communication
  • Fire and alarm linkage : Optional

Software and Database Supported

  • eSSL Professional Door Control Software
  • Database Type:- MS Access / MS SQL1
